Virtual Breadboard is a freeware design and learning solution that includes all of the necessary capabilities to allow you to create intelligent connected electronic apps and complete your duties without spending any money. It can be used on the Hub, HoloLens, mobile devices, and computers The tool is ideal for people who want to expand their expertise. You may choose and drop apps using the growing variety of virtualization components, which saves time. For that purpose - it is an excellent tool and well worth the money.It is one of the Best iCircuit Alternatives. I would recommend this application to anyone, like me, who is an amateur electrical engineer who only needs to build simple circuits. The automatic re-draw of the wire/connectors between components can also be annoying (but is ok nonetheless). The application crashes sometimes but not as much as the previous versions, and definitely within an 'annoyance' tolerance. The universe of integrated circuits expanded in 1.3.4 but still could do with some more. The simulation of the circuits is ok, very sufficient for an amateur, but anything complex tends to 'bug out'. The application itself is also not so complex, so not a great deal to learn I picked up almost everything in 2 uses. MS Visio, this has a '.drag, drop and connect.' GUI. The application itself is easy and simple to use.
#Icircuit lollipop full#
It might be a little limited for anyone who is qualified/educated in electrical engineering wanting a full simulation of complex circuits. I've used it many times to design and test circuits prior to committing solder to wire. Great app for simple circuits/amateurs, teachers, etc.
#Icircuit lollipop manual#
* Dark mode and light mode can now be automatic or manual * Better contrast in the element popup editor * Resistance, Frequency, RMS, PP, Min and Max Voltage measurement mode on Gauge * Improved support for Arduino structs and arrays * Rotate command to quickly re-orient elements * Wire colors with controllable thickness Version 1.12.2 improves subcircuits and contains all the new features and bug fixes from the big 1.12 release: I hope you love the ease of simulating circuits with iCircuit!
#Icircuit lollipop Offline#
Scope data can even be exported for offline analysis. You can even export your circuits and PNGs, PDFs, and SVG files so that they are easy to include in reports or web sites. The scope can simultaneously track many signals over time and features a variety of automatic modes that make it easy for you to grasp the behavior of your circuit. If you want to see how a value changes over time, then you can add values to the built-in oscilloscope. The app features a multimeter that you use to probe around the circuit to instantly read voltages and currents. The app has everything from simple resistors, to switches, to MOSFETS, to digital gates. There are over 300 elements you can use to build your circuits. Instead, you just play with the circuit as you normally would, with the power on!
You do not stop to take a measurement or spend a lot of time configuring reports. It's just like working with the real circuit.
But iCircuit is unlike other CAD programs because it is always simulating. You use it as you would any CAD program: you add elements, connect them together, and set their properties. It is the perfect companion to students, hobbyists, and engineers. Its advanced simulation engine can handle both analog and digital circuits, Arduino microcontrollers, and features realtime always-on analysis. ICircuit is the easiest way to design and experiment with circuits.
